DC-CS1100.1
Amplifier Description
The DC-CS 1000.1 is a compact series amplifier capable of making 1,100 watts. Its High power mono block. It has 4awg inputs and onboard clipping lights. It also comes with a bass knob and a clipping indicator. Designed to make more power in less space.
Output Power (RMS)
4 ohm 500Wx1 @ 14.4 Volts
2 ohm 800Wx1 @ 14.4 Volts
1 ohm mono 1100x1 @ 14.4 Volts
1 ohm mono 1400x1 @ 16.0 Volts
Key Features
• 1 ohm stable
• Variable low pass filter
• Variable subsonic filter
• Wired Bass Knob remote control W/ Clip light
• RCA Pass Thru
• Onboard clip light
1100x1 at 4 ohm
1100x1 at 2 ohm
1100x1 at 1 ohm
AMP SPECS:
| DC Amp Model: | CS 1100x1 |
|---|---|
| Input Sensitivity | 6V~0.2V |
| Frequency Response | 10Hz~250Hz |
| 24dB / Octave Crossover | YES |
| Low Pass | 35Hz ~ 250Hz |
| Subsonic Filter | 10Hz-50hz |
| Bass Boost @45hz | NO |
| Phase Shift | NO |
| Remote Control | Yes |
| Clip Indicator | Yes |
| Signal to Noise Ratio | dB92 |
| Damping Factor | 150< |
| THD @ 4ohms | Less than 0.1% |
| Fuse Rating | External 100 amp |
| LED Status Lights | Power/Protect/Clip |
| Master/Slave | NO |
| Heatsink Length | 8.27"/210mm |
| Heatsink Width | 4.72"/120mm |
| Heatsink Height | 1.96"/50.0mm |
